Arch BLE
Board mBed basada en Nordic nRF51822 con módulo Bluetooth (BLE). Posee conectores compatibles con Arduino.
COD: SE810003001
Peso: 0.050 Kg
Disponibilidad: En Stock
ARS 78129.00
El producto no está disponible para la venta en este momento
Características
Description
Arch BLE is an mbed enabled development board based Nordic nRF51822. With Arduino form factor and Grove connectors, it is extremely easy to create a bluetooth low energy device.
The nRF51822 is a powerful multi-protocol single chip solution for ULP wireless applications. It incorporates Nordic’s latest best-in-class performance radio transceiver, an ARM Cortex M0 CPU and 256kB flash + 16kB RAM memory. The nRF51822 supports Bluetooth® low energy and 2.4 GHz protocol stacks.
Features
mbed enabled
•Online IDE
•Easy to use C/C++ SDK
•Handy libraries
CMSIS DAP based on LPC11U35
•Drag-n-drop programming
•Debug using CMSIS DAP standard
•USB virtual serial for communication
Arduino form factor with Grove connectors
Nordic nRF51822 Multi-protocol Bluetooth® 4.0 low energy/2.4GHz RF SoC
•ARM Cortex M0 processor
•256kB flash/16kB RAM
•Configurable I/O mapping for digital I/O
USB Micro B connector
Documents
Please visit our wiki page for more info about this product.
Schematic (320 Kb)
