7 inch LCD HDMI Touch Screen Display TFT LCD Panel Module 800x480
Panel TFT LCD de 7 pulgadas con tecnología táctil capacitiva, el cual ofrece una resolución de 800*480. Incluye CD con utilidades, cable micro USB, cable HDMI, y un juego de tornillos para montaje. Dispone de la posibilidad de activar o no la opción de Backlight.
COD: HTHR0121
Peso: 0.400 Kg
Disponibilidad: Sin Stock
ARS 103694.00
El producto no está disponible para la venta en este momento
Características
Description:
I am 7 inch HDMI display for raspberry pie making, 800x480 HD resolution, with capacitive touch screen.
Of course, I also not limited to use raspberry pie.
Can say, I am also a universal HDMI display, you can will I use the other mini PC (to drive), or even as a computer monitor.
If you need a HDMI display, eager to change the world, no one can stop you.
Of course, I also not limited to use raspberry pie.
Can say, I am also a universal HDMI display, you can will I use the other mini PC (to drive), or even as a computer monitor.
If you need a HDMI display, eager to change the world, no one can stop you.
- 800 x 480 HD resolution
- Capacitive touch control
- Support Pi Raspberry
- Support Pi Banana, Pro Banana, provide Lubuntu, Raspbian corresponding mirror
- Support Black BB, provide the corresponding mirror image Angstrom
- General HDMI display, can be used as a computer monitor
- HDMI interface is used to display and USB interface is used to touch
- Support the backlight control, saves the electricity
Rev1.1 version(unscrupulous merchant piracy is the version of the cottage):
- Using a proprietary HID protocol, porting to your system is more difficult
- When used with Raspberry Pi, access Raspbian or Ubuntu system need to install the driver, does not support Windows 10 IoT
- When used as a computer monitor, you can't touch it.
Rev2.1 version(upgrade version):
- Use standard HID protocol, you can into their systems
- When used with Raspberry Pi, support Raspbian, Ubuntu, 10 IoT Windows, single point touch, to avoid flooding
- Used as a computer display, supports Windows 10/8.1/10/8.1, touch until five o 'clock, avoid flooding
The mini PC support description:
| model | drive | The mirror |
|---|---|---|
| Raspberry Pi B | Raspbian | Raspbian |
| Raspberry Pi A+ | Raspbian | Raspbian |
| Raspberry Pi B+ | Raspbian | Raspbian |
| Raspberry Pi 2 Model B | Raspbian | Raspbian,Ubuntu,Windows 10 IoT |
| Banana Pi | -- | Raspbian,Lubuntu |
| Banana Pro | -- | Raspbian,Lubuntu |
| BB Black | -- | Angstrom |
Note:
- Driver: you can use on the use of system. Such as Raspbian drive, add to your Raspbian system, can support the display and touch.
- You cannot use mirror: in the use of the system. The mirror is an independent system, we provide support for image, display and touch
The product includes:
1. 7inch HDMI LCD (B)× 1
2. HDMI connection line * 1
3. HDMI connection line * 1
4. RPi copper column package (4 PCS) x 1
5. Data CD * 1
